G2153
Part #: G2153
Model Number:
MG00XEB0-20UKR3-7UKA6A10-S
Category:
Basic
Sub Category:
Standard
Power Configuration:
13A, 230V, 2.9kW
Physical Configuration:
66in / 1683mm, Vertical
Product Summary:
rPDU, Basic Standard, 13A, 230V, 2.9kW, Vertical, (20) BS1363, 3m power cord with BS1363, Black Powder Coat.
Plug Form:
BS1363Receptacle:
BS1363 (Quantity: 20)Chassis Color Options:
To discuss color options, contact your local sales representative.
Product Specification and Options
System Features
| Quantity Of Inputs | 1 |
| Voltage | 200-240V |
| Current | 13A |
| VA per Input (Load Capacity) | 2.9kW (230V) |
| Frequency | 50/60Hz |
| Over Current Protection | None |
| Switch | Green neon with protective cover |
| Power Cable Wire Gauge | 1.5mm² PVC |
| Power Cable Length | 3m |
| Plug Type | BS 1363P |
| Receptacle/Socket Type #1 | BS1363 |
| - Quantity on Face | 20 |
| - Style | Individual - Right Hand Angled |
| - Maximum Output per Receptacle/Socket | 13A |
| - Voltage per Receptacle/Socket | 230V |
| Maximum Operating Temperature | 60C / 140F |
| Heavy Steel - Powder Coat Finish | Black |
| Configuration | 66in / 1683mm Vertical Rackmount |
| GE Vertical Mounting Bracket | Yes |
| Toolless Mounting Hardware - Center to Center Spacing | 1556mm and 1645mm |
| Product Warranty | 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years |
| Certification/Agency Approvals | CE Marked |
| Certification/Agency Approvals | UKCA Marked |
| Certification/Agency Approvals | Complies with IEC 62368-1 (DOC Available) |
| Certification/Agency Approvals | Complies with EN 55032 and EN 55035 |
| Certification/Agency Approvals | RoHS Compliant |
| Certification/Agency Approvals | Cم Mark |
| Chassis Dimensions (LxWxD) | 1683mm x 54mm x 50mm |
| Shipped Weight | 14lbs (6.35kg) |
