VP4N6300
Part #: VP4N6300
Model Number:
MN05MDR1-18I6B3-6PS56B0F10-S
Category:
Monitored
Sub Category:
Unit Level
Power Configuration:
60A, 200-240/346-415V WYE, 34.5kW
Physical Configuration:
19in / 483mm, Horizontal
Product Summary:
rPDU, Monitored Unit Level, 60A, 240/415V WYE, 34.5kW, Horizontal, (6) IEC C13, (12) IEC C19, 10ft power cord with 3P+N+E (IP44), Black Powder Coat.
Monitoring:
Input and per Phase power monitoring with Circuit/Breaker current monitoring. Environmental monitoring via optional remote sensors. Daisy chain Ethernet connectivity. Local high visibility display.
Plug Form:
3P+N+E (IP44)Receptacle:
IEC C19 (Quantity: 12)
IEC C13 (Quantity: 6)Chassis Color Options:
To discuss color options, contact your local sales representative.
Product Specification and Options
System Features
| Monitoring | Input and per Phase power monitoring with Circuit/Breaker current monitoring. Environmental monitoring via optional remote sensors. Daisy chain Ethernet connectivity. Local high visibility display. |
| Input Monitoring | Total Unit Monitoring (kWh, W, VA, PF) Phase (A, B, C) Monitoring (kWh, W, VA, PF, V, A) Power Measurements Compliant with ANSI C12.1 and IEC 62053-21 at 1% Accuracy Class Requirements |
| Quantity Of Inputs | 1 |
| Voltage | 200-240/346-415V WYE |
| Current | 60A x 3 Phase WYE |
| VA per Input (Load Capacity) | 34.5kW (240V) |
| Frequency | 50/60Hz |
| Over Current Protection | (12) 20A Single Pole Magnetic Breakers (10kAIC Rated) |
| Switch | Breaker/Switch Combination |
| LCD Touchscreen Display / Auto Oriented | Yes |
| Power Cable Wire Gauge | 6/5 Type W |
| Power Cable Length | 10ft |
| Power Entry Location | Right Rear |
| Plug Type | IEC60309 3P + N + E, 60A, 240/415V, Splashproof IP44 |
| Receptacle/Socket Type #1 | IEC C13 |
| - Quantity on Face | 6 |
| - Quantity per Breaker | Breakers 1,3,5,7,9,11 = 1 |
| - Quantity per Phase | 2 |
| - Style | Individual |
| - Voltage per Receptacle/Socket | 240V (L-N) |
| Receptacle/Socket Type #2 | IEC C19 |
| - Quantity on Face | 12 |
| - Quantity per Breaker | 1 |
| - Quantity per Phase | 4 |
| - Style | Individual |
| - Voltage per Receptacle/Socket | 240V (L-N) |
| Internal RMS Voltage Sensor | Yes |
| Internal RMS Current Sensor | Yes |
| Network Connection | Dual 10/100/1000Mbps Ethernet |
| Protocols Supported | DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+, Modbus TCP |
| Data Access Formats | CSV datalog, JSON API, JSON datalog |
| USB Support | Yes |
| IP Reset Button | Yes |
| Hard Reboot Button | Yes |
| Serial Connection | RS232 via RJ45 |
| Remote Sensor RJ Connection Jacks | 1 (Supports up to 16 Sensors) |
| Maximum Operating Temperature | 60C / 140F |
| Heavy Steel - Powder Coat Finish | Black |
| Optional External Ground | Yes |
| Configuration | 19in / 435mm 2U Horizontal Rackmount |
| 19in Recess Mount | Yes |
| Rear Support Brackets | Yes - Adjustable |
| Country of Origin | USA, TAA Compliant and Buy American Act COTS Compliant |
| Product Warranty | 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years |
| Certification/Agency Approvals | UL & c-UL Listed 62368-1 |
| Certification/Agency Approvals | RoHS Compliant |
| Certification/Agency Approvals | FCC Part 15 Class A Conformance |
| Chassis Dimensions (HxWxD) | 3.4in x 17in x 29in / 88mm x 435mm x 740mm |
| Shipping Weight | 25 lbs (11.3 kg) |
